Type-SG9323
Introduction：
Single channel blue light gel cutting equipment, using blue light CCD imaging recognition, is applied for molecular localization, cutting, extraction, sorting and other operations in DNA and protein electrophoresis, as well as experimental operations in the field of life science research such as cells and proteomics.
Features:
1,Blue light module
2,CCD photo module
3,UV sterilization lamp and lighting module
4,Air purification system, etc.
5,Self-developed cutting head-----Using PC (polycarbonate) material, with corrosion resistance, impact resistance, resistance to heat, cold and other properties.
Specification
| Instrument | SG9323 Bands of Gel detecting and cutting system |
| Functional module | Blue-ray Module,CCD Module, Gel Cutting Module |
| Gel cutting channel | 1 |
| Robotic arm accuracy | ±0.01mm |
| Software | ZWorks automation software, Api interface available |
| Software Running Platform | Windows |
| Software interface | USB Interface,RS-232 Serial Port |
| Power Requirements | Input voltage: 100-240VAC±10 %, frequency 50/60Hz±5%; output:24V |
| Working environment | 15-40℃.relative humidity 20-80%,non-condensing |
| Net weight | 70KG |
| Size | 780x710x1000mm |
