BRIEF DESCRIPTION：
Uncapping and scanning code pipetting allows to load the samples with the original tube with cap. It supports automatic cap opening and closing, automatic data entry, fast and accurate dispensing and identification judgment. It greatly saves manpower, reduces the pressure of laboratory space and improves the detection capacity.
KEY FEATURES AND BENEFITS：
1.Uncapping and code-scanning pipetting is a desktop pipetting workstation designed to automate the scanning, uncapping, loading, pipetting, and dispensing processes.
2.It is equipped with a set of single-channel pipetting modules for 1-200μl, and can be used to run a variety of automated processes of loading and mixing samples.
3.Scanner
Automatic recognition of sample tube and reagent codes
4.Uncapping module
Automatic opening and closing of reagent tubes
5.Liquid level detection module
The infrared backlight board is equipped with an infrared camera to recognize and judge the liquid level
Specification
| Instrument | SC9310-D56 Uncapping and code-scanning pipetting |
| Pipetting range | 1-200μL |
| Channels | single channel module |
| Samples | 192 |
| Precision | 1μL.CV≤5% |
| Qrcode recognition | Rotary jaw gripping, dynamic recognition by code scanner |
| Liquid level recognition | Infrared camera, infrared backlight board with the use of, to avoid external interference |
| Power requirements | Input:100-240VAC±10%,Frequency 50/60Hz±5%; Output:24V |
| Safety requirement | Filtering function negative pressure system, open door pause alarm system |
| Interface | 2 USB,1 Ethernet port |
| Working environment | 15-40℃, Relative humidity 20-80%, non condensing |
| Air/vacuum | 28 l/min at 6.2-6.9 bar; 63.5 cmHg at 14 l/min |
| Size | 1230 x915x1050mm |
